Polyethylene PE1000 Crane Outrigger Pads -UHMWPE
Description:
High quality high performance UHMWPE / HDPE outrigger pads.
Advantages in severe environment conditions :
| simple to install and requires virtually no maintenance |
| unlimited lifetime warranty |
| ergonomic & environmentally friendly |
| easy to clean |
| hand cut-outs for field handling |
Polyethylene crane outrigger pad common size & loading capacity :
Common size of square pad :
|
Size (mm) |
Weight(kg) |
Vertical Jack capacity (Ton) |
Crane Capacity (Ton) |
|
400*400*40 |
6.3 |
10 |
12 |
|
500*500*40 |
9.9 |
12 |
15 |
|
600*600*40 |
14.2 |
20 |
25 |
|
700*700*40 |
19.4 |
22 |
30 |
|
800*800*40 |
25.3 |
25 |
30 |
|
1000*1000*40 |
39.2 |
30 |
35 |
|
400*400*50 |
8 |
11 |
15 |
|
500*500*50 |
12.2 |
15 |
18 |
|
600*600*50 |
18 |
23 |
30 |
|
800*800*50 |
31.3 |
30 |
35 |
|
1000*1000*50 |
48 |
40 |
50 |
|
400*400*60 |
9.5 |
12 |
15 |
|
500*500*60 |
14.5 |
20 |
25 |
|
600*600*60 |
21.2 |
25 |
30 |
|
800*800*60 |
38.4 |
35 |
45 |
Common size of round pad :
|
Size(mm) |
Weight(kg) |
Vertical Jack Capacity (Ton) |
Crane Capacity (Ton) |
|
800*50 |
25 |
25 |
30 |
|
900*50 |
30 |
30 |
40 |
|
1000*50 |
38.5 |
35 |
45 |
|
800*60 |
30 |
30 |
35 |
|
900*60 |
37.5 |
35 |
45 |
|
1000*60 |
40 |
40 |
50 |
|
1000*80 |
61.5 |
70 |
80 |
|
1200*80 |
110 |
100 |
120 |
