High Density Polyethylene, is a polyethylene thermoplastic, common called “HDPE” or "polythene” With a high strength-to-density ratio, HDPE is used in the production of plastic bottles, corrosion-resistant piping, geomembranes, and plastic lumber.
BEYOND is the first to produce the ultra -thick HDPE plate (with a thickness up to 200mm) in China, whom started to research, develop and produce HDPE plates and rods in 2015. With the imported and unique technology of residual streaa relieving and entirely virgin PE material without any reclaimed material added, for many years of innovation and improvement, such plates is free from issues such as deforming, bubble or easy rupture.
Specification:
| Type | extruded |
| Size | 1000*2000mm or 1220*2440mm |
| Thickness | 1---200mm |
| Density | 0.96 g/cm³ |
| Color | White / black / blue / green / yellow |
| Brand name | BEYOND |
| Material | 100% virgin material |
| Sample | FREE |
| Acid resistance | YES |
| Ketone Resistance | YES |
Physical Datasheet:
| Item | HDPE sheet |
| Color | White / Black / Green |
| Proportion | 0.96g/cm³ |
| Heat resistance (continuous) | 90℃ |
| Heat resistance (short-term) | 110 |
| Melting point | 120℃ |
| Glass transition temperature | _ |
| Linear thermal expansion coefficient
(average 23~100℃) |
155×10-6m/(m.k) |
| Flammability(UI94) | HB |
| (Dipping into water at 23℃ | 0.0001 |
| Bending tensile stress/ Tensile stress off shock | 30/-Mpa |
| Tensile modulus of elasticity | 900MPa |
| Compressive stress of normal strain-1%/2% | 3/-MPa |
| Friction coefficient | 0.3 |
| Rockwell hardness | 62 |
| Dielectric strength | >50 |
| Volume resistance | ≥10 15Ω×cm |
| Surface resistance | ≥10 16Ω |
| Relative dielectric constant-100HZ/1MHz | 2.4/- |
| Bonding capacity | 0 |
| Food contact | + |
| Acid resistance | + |
| Alkali resistance | + |
| Carbonated water resistance | + |
| Aromatic compound resistance | 0 |
| Ketone resistance | + |
Post time: Nov-21-2023
